Unleash robust power and unwavering reliability with the RATO R390 Horizontal Shaft Engine, engineered to excel in demanding applications. This formidable 13hp, 301cc, 4-stroke OHV single-cylinder engine delivers exceptional performance, making it a true workhorse for your machinery. With a substantial net power output of 8.4kW at 3600rpm and a strong 25Nm of net torque at 2,500rpm, it's built to tackle tough jobs with remarkable ease. The precise 25.4mm horizontal shaft ensures broad compatibility, making it an ideal replacement or upgrade for a wide range of equipment. Trust in its steadfast construction, backed by a comprehensive 2-year or 500-hour domestic warranty, providing you with peace of mind for every project.
Features
- 13 HP 4 stroke OHV engine – 301cc
- Horizontal Shaft
- Net Power: 8.4kw (3600rpm)
- Net Torque: 25Nm (2,500rpm)
| Model # | R390 |
| UPC | 6418914916791 |
| Brand | RATO |
| Shipping Weight | 30.5000kg |
| Type | OHV Engine |
| Weight | 30.5 kg |
| Bore x Stroke | 88 x 64mm |
| Compression Ratio | 8.5:1 |
| Displacement | 389cc |
| Starting System | Recoil start |
| Dimensions | 465 x 415 x 440 mm |
| Manufacturer Warranty | 2 Years / 500 Hours Warranty |
| Net Power | 8.4kW / 3600rpm |
| Net Torque | 25N.m / 2500 |
| Shaft Orientation | Horizontal |
| Pto Shaft Rotation | CCW |
| Shaft Size | 25.4mm (1") |
